ICC Precast Tack Tile 300x300x80mm (Warning/Directional)
| Lead Time Days | 7 |
|---|---|
| Unit Of Measure | Nos. |
| Weight (kg) | 18.000000 |
| Width | 300 |
| Length | 300 |
| Thickness | 80 |
| Country of Manufacture | Sri Lanka |
| Country of Origin | Sri Lanka |
| Brand | ICC |
| Primary Material | Concrete |
| Colour | Gray |
| Warranty Period | N/A |
PRODUCT SUMMARY:
International Construction Consortium (Pvt) Ltd is the leading of manufacturer of precast concrete Tactile pavings and other associated precast products in Sri Lanka. They are available in accordance with the RDA standards and other standard specifications also. The tactile pavings are manufactured with high quality controlling and quality assurance systems under engineer supervision.
Tactile pavings are most often used for pedestrian path construction work for special needs persons. (Please refer the general data sheet). Tactile pavings are also known as tactile tiles.
GENERAL SPECIFICATIONS:
- Details Specification – RDA Standard And Project Standard
- Raw Material Specification – BS / ASTM / SLS Standard
- Concrete Strength : 30kN/mm2
- Curing Period (Min.) : 7 Days
- Stacking & Packing : wooden Pallet (1200mm x1200mm)
- Quantity for a wooden Pallet: 72 Nos.
- Type of tile : Warning and Direction
CLIENT RESPONSIBILITIES
- Selection of correct & required Items prior to purchase.
- Check & get the confirmation of stock availability before the purchase.
- Vehicle access path should be clear.
- Unloading should be arranged by the client.
- If the transportation is arranged by client, vehicles should be suitable.
- Pallet quantity for a 6 Wheel 20 feet long flatbed Vehicle: 08 Nos.
- Pallet quantity for a 10 Wheel 23 feet long flatbed Vehicle: 10 Nos.
- Do not stay in hazardous areas while unloading.
COMPLETED PROJECTS:
PROJECT NAME | QUANTITYNOS. |
| D.R.W. Wijewardoana Mawatha Road Construction Project | 150 |
| Habarana – Kanthale Road Construction Project | 135 |
| Habarana – Thonigala Road Construction Project | 205 |
| A9 & Mulathive – Paranthan Road Construction Project | 125 |
